| uF - Micro Farads pF - Pico Farads
nF - Nano Farads
K- Kilo Ohms
M - Mega Ohms
Pot - Potentiometer
uH - Micro Henries
H - Henries
Trim - Trimmer
If a resistor has a number for a value but no letter after it, it is assumed to be in
Ohms. All resistors are assumed to be ¼ of a Watt unless otherwise specified.
If a capacitor has a number for value but no letter after it, it is assumed to be in Micro
Farads (uF). |
