Power Supply - Variable -- 1.2V To 25V At 4A |
 |
 |
... |
|
|
... |
|
|
Power Supply - Variable -- 1.2V To 25V At 4A |
|
|
... |
|
| Parts List: | |||
| Component: | Value: | Datasheet: | Qty: |
| Resistor | 1K | Not Available | 01 |
| Resistor | 1.2K | Not Available | 01 |
| Resistor | 4.7K Pot | Not Available | 01 |
| Resistor | 100 | Not Available | 01 |
| Resistor | 270 | Not Available | 01 |
| Resistor | 33 | Not Available | 01 |
| Capacitor | 10,000uF, 40V | Not Available | 01 |
| Capacitor | 220uF, 25V | Not Available | 01 |
| Capacitor | 10uF, 63V | Not Available | 01 |
| Diode | 1N4148 | Available | 02 |
| Diode | Zener, 12V-1W | Not Available | 01 |
| Diode | Bridge, 50V-6A | Not Available | 01 |
| Transistor | BC327 | Not Available | 01 |
| Transistor | BC137 | Not Available | 01 |
| Transistor | 2N3055 | Available | 01 |
| IC | 741 | Available | 01 |
